LiuGong 920E Excavator
The LiuGong 920E is a robust 21.5-ton excavator built for dependable digging performance,
strong hydraulics, and jobsite efficiency across general construction and heavy-duty work.
strong hydraulics, and jobsite efficiency across general construction and heavy-duty work.
Highlights:
- Operating weight: 21,500 kg
- Rated power: 112 kW @ 1,950 rpm
- Max digging depth: 6,562 mm
- Bucket capacity: 1.0 m³
- Bucket digging force (ISO): 152.5 kN
Key Specifications
| Operating weight | 21,500 kg |
| Engine | Cummins 6BTAA5.9-C150-II |
| Emissions | Tier 2 / Stage II |
| Rated power | 112 kW (150 hp) @ 1,950 rpm |
| Net power | 102 kW (137 hp) @ 1,950 rpm |
| Peak torque | 614 N·m @ 1,500 rpm |
| Max digging depth | 6,562 mm |
| Bucket capacity | 1.0 m³ |
| Main pumps total flow | 448 L/min |
| Relief pressure (main) | 34.3 MPa |
| Swing speed | 12.5 rpm |
| Max travel speed | 5.7 km/h |
| Drawbar pull | 220 kN |
| Fuel tank | 420 L |
| Hydraulic reservoir | 210 L |
| Hydraulic system total | 330 L |
| Bucket digging force (ISO) | 152.5 kN |
| Arm digging force (ISO) | 105 kN |
